Fraksiyonel HP dvigateli

Qulay narx, tez yetkazib berish, oʻz vaqtida xizmat koʻrsatish-- ANG – bu yuqori samaradorlik, past shovqin, past harorat koʻtarilishi, uzoq xizmat muddati va hokazo boʻlgan Fraksiyonel HP motorining ishonchli yetkazib beruvchisidir.

So'rov yuborish

Mahsulotni tanishtirish

Fraksiyonel HP dvigatelining xususiyatlari

1. 100 foiz mis o'rash simlari, 100 foiz chiqish quvvati, yuqori sifatli sovuq rulonli silikon po'latdir.

2. Dinamik jihatdan muvozanatli, original tuzilish va jozibali ko'rinish.

3. Yuqori samaradorlik va quvvat omili, energiyani tejash.

Fraksiyonel HP dvigatelining spetsifikatsiyasi

Motor seriyasi	MS seriyasi, YL seriyasi va boshqalar.	Nominal quvvat	6w ~ 750w, 1HP dan past, 1/8HP 1/6HP 1/4HP 1/3HP 1/2HP 3/4HP kabi
Polyaklar soni	2 qutb, 4 qutb, 6 qutb, 8 qutb	Samaradorlik	IE1 / IE2 / IE3 / IE4
Kuchlanishi	110V 115V 220V 230V 380V 400V 415V 440V	Chastotasi	50Hz, 60Hz
Himoya klassi	IP54, IP55, IP56, IP65, IP66, IP67, IP69K suv o'tkazmaydigan	Izolyatsiya darajasi	F
Sovutish usuli	IC411, IC410, IC416, TENV, TEFC	Doimiy ish majburiyati	S1, S2, S3, S4, S5, S6, S7, S8
Boshlash rejimi	To'g'ridan-to'g'ri onlayn boshlash	Transport paketi	Kontrplak qutisi
Ramka materiali	Alyuminiy qotishmasi yoki zanglamaydigan po'lat	Kelib chiqishi	Xanchjou, Xitoy
O'rnatish pozitsiyasi	IMB3/B5/B35/B14/B34	HS kodi	8501520000 / 8501530090
Sertifikatlash	Idoralar	Spetsifikatsiya	56B5, 56B14, 63B5, 63B14, 71B5, 71B14, 80B5, 80B14, 90B5, 90B14
Aksessuarlar	Spiral vites qutisi, chuvalchangli reduktor, planetar reduktor, termal himoya, majburiy sovutish foniy, yomg'ir qopqog'i va boshqalar.	Kafolat muddati	12 oy

Nima uchun fraksiyonel ot kuchi motorimizni tanlaymiz?

advantage of ac motor

Fraksiyonel ot kuchi dvigateli tafsilotlari

description of ac motor

Bir nechta dastur

Odatda, u nam, chang yoki iflos muhitda o'rnatilgan suv nasoslari, fanatlar, shamollatgichlar, kompressorlar, konveyerlar va boshqa sanoat mashinalarida qo'llaniladi.


Mashinasozlik	Kon uskunalari	Elektr jihozlari

Sanoat	Oziq-ovqat mahsulotlarini qayta ishlash	Metallurgiya

MS seriyali uch fazali alyuminiy elektr motori

Model	Nominal chiqish		Kuchaytirgichlar (A)	Tezlik r/min	Chastotasi (HZ)	LRT/RLT	BDT/RLT
Model	kVt	HP	380V	Tezlik r/min	Chastotasi (HZ)	LRT/RLT	BDT/RLT
MS561-2	0.09	1/8	0.29	2700	50	2.2	2.1
MS562-2	0.12	1/6	0.37	2700	50	2.2	2.1
MS63M1-2	0.18	1/4	0.53	2720	50	2.3	2.3
MS63M2-2	0.25	1/3	0.69	2720	50	2.3	2.3
MS71M1-2	0.37	1/2	1.01	2755	50	2.2	2.3
MS71M2-2	0.55	3/4	1.38	2790	50	2.3	2.3

Model	Nominal chiqish		Kuchaytirgichlar (A)	Tezlik r/min	Chastotasi (HZ)	LRT/RLT	BDT/RLT	LRA/RLA	EFF (foiz)	Quvvat omili (cosph)
Model	kVt	HP	380V	Tezlik r/min	Chastotasi (HZ)	LRT/RLT	BDT/RLT	LRA/RLA	EFF (foiz)	Quvvat omili (cosph)
MS561-4	0.06	1/12	0.23	1300	50	2.1	2	4	56	0.7
MS562-4	0.09	1/8	0.33	1300	50	2.1	2	4	58	0.72
MS63M1-4	0.12	1/6	0.44	1310	50	2.2	2.1	4.4	57	0.72
MS63M2-4	0.18	1/4	0.62	1310	50	2.2	2.1	4.4	60	0.73
MS71M1-4	0.25	1/3	0.79	1340	50	2.2	2.1	5.2	65	0.74
MS71M2-4	0.37	1/2	1.12	1340	50	2.2	2.1	5.2	57	0.75
MS80M1-4	0.55	3/4	1.52	1390	50	2.3	2.4	5.2	71	0.75

Model	Nominal chiqish		Kuchaytirgichlar (A)	Tezlik r/min	Chastotasi (HZ)	LRT/RLT	BDT/RLT	LRA/RLA	EFF (foiz)	Quvvat omili (cosph)
Model	kVt	HP	380V	Tezlik r/min	Chastotasi (HZ)	LRT/RLT	BDT/RLT	LRA/RLA	EFF (foiz)	Quvvat omili (cosph)
MS71M1-6	0.18	1/4	0.74	870	50	2	1.9	4	56	0.66
MS71M2-6	0.25	1/3	0.95	870	50	2	1.9	4	59	0.68
MS80M1-6	0.37	1/2	1.23	880	50	2	1.9	4.7	62	0.7
MS80M2-6	0.55	3/4	1.7	880	50	2.1	1.9	4.7	65	0.72
MS80M1-8	0.18	1/4	0.83	645	50	1.9	1.8	3.3	51	0.61
MS80M2-8	0.25	1/3	1.1	645	50	1.9	1.8	3.3	54	0.61
MS90S-8	0.37	1/2	1.49	675	50	1.9	1.8	4	62	0.61
MS90L-8	0.55	3/4	2.17	680	50	2	1.8	4	63	0.61

Bir fazali asenkron elektr motorining MY seriyali kondansatkichlari

Model	Quvvat (KVt)	Kuchlanishi (V)	Hozirgi (A)	Tezlik (d/daq)	EFF (foiz)	Quvvat omili	Tstart /Tn (Vaqt)	Tmax/Tn (Vaqt)
MENING631-2	0.18	220	1.48	2800	65	0.92	0.4	1.7
MENING632-2	0.25	220	1.96	2800	66	0.92	0.4	1.7
MENING711-2	0.37	220	2.73	2800	67	0.92	0.35	1.7
MENING712-2	0.55	220	3.88	2800	70	0.92	0.35	1.7

MC seriyali kondensatorni ishga tushirish bir fazali elektromotor

Model	Quvvat (KVt)	Kuchlanishi (V)	Hozirgi (A)	Tezlik (d/daq)	EFF (foiz)	Quvvat omili	Tstart /Tn (Vaqt)	Tmax/Tn (Vaqt)	Boshlovchi A (uf/v)	Quyosh Imkoniyat (uf/v)
MC711-2	0.18	220	1.89	2800	60	0.72	3	1.8	12	75uf/300v
MC712-2	0.25	220	2.04	2800	64	0.74	3	1.8	15	75uf/300v
MC801-2	0.37	220	3.36	2800	65	0.77	2.8	1.8	21	100uf/300v
MC802-2	0.55	220	4.65	2800	68	0.79	2.8	1.8	29	150uf/300v
MC711-4	0.12	220	1.88	1400	50	0.58	3	1.8	9	75uf/300v
MC712-4	0.18	220	2.49	1400	53	0.62	2.8	1.8	12	75uf/300v
MC801-4	0.25	220	3.11	1400	58	0.63	2.8	1.8	15	100uf/300v
MENING802-4	0.37	220	4.24	1400	62	0.64	2.5	1.8	21	100uf/300v
MC90S-4	0.55	220	5.49	1400	66	0.69	2.5	1.8	29	100uf/300v

YC/YCL seriyali og'ir ish bir fazali kondansatör ishga tushirish AC elektromotori

Model	Nominal chiqish		Tezlik (r.p.m)	Hozirgi (A)	Eff.( foiz )	Quvvat omili (chunki)	lst/ln	Tst/Tn
Model	kVt	HP	Tezlik (r.p.m)	Hozirgi (A)	Eff.( foiz )	Quvvat omili (chunki)	lst/ln	Tst/Tn
YC711-2	0.18	1/4	2800	1.9	63	0.7	6.5	3
YC712-2	0.25	1/3	2800	2.4	65	0.72	6.5	3
YC80A-2	0.37	1/2	2840	3.5	66	0.74	6.5	3
YC80B-2	0.55	1	2850	6.68	68	0.75	6.5	3
YC711-4	0.12	1/6	1450	1.9	48	0.58	6	3
YC712-4	0.18	1/4	1450	270	50	0.6	6	3
YC80A-4	0.25	1/3	1450	3.52	52	0.62	6	3
YC80B4	0.37	1/2	1450	4.69	56	0.61	6	3
YC80C-4	0.55	3/4	1450	6	60	0.65	6	3

Model	Quvvat (kv	Tezlik (d/daq)	Hozirgi (A)	(A) Voltaj (V)	EFF (foiz)	Quvvat Faktor (CosΦ)	LRT	BDT	LRA	Shovqin dB (A)
Model	Quvvat (kv	Tezlik (d/daq)	Hozirgi (A)	(A) Voltaj (V)	EFF (foiz)	Quvvat Faktor (CosΦ)	RLT	RLT	RLA	Shovqin dB (A)
YCL711-2	0.37	2800	2.7	220	67	0.92	1.8	1.7	16	72
YCL712-2	0.55	2800	3.9	220	70	0.92	1.8	1.7	21	72
YCL711-4	0.25	1400	2.0	220	62	0.92	1.8	1.7	12	67
YCL712-4	0.37	1400	2.8	220	65	0.92	1.8	1.7	16	67
YCL801-4	0.55	1400	4.0	220	68	0.95	1.8	1.7	21	70

Kompaniya taqdimoti

Ushbu havolani bosish orqali ishlab chiqaruvchining videosini tomosha qiling

AC motor production

Sertifikat

AC motor uchun Idoralar

DC motor uchun Idoralar

TSS

Savol: Elektr motorini qaysi hududlarga yetkazib bera olasiz?

A: Keniya, Gana, Hindiston, Shri-Lanka, Pokiston, Indoneziya, Malayziya, Buyuk Britaniya, Yevropa, Angliya, Italiya, Fransiya, Germaniya, Ispaniya, Niderlandiya, Shveytsariya, Rossiya, Avstriya, Belgiya, Xorvatiya, Chexiya, Daniya, Finlyandiya, Vengriya, Islandiya, Lyuksemburg, Monako, Norvegiya, Portugaliya, Ruminiya, Shvetsiya, Turkiya, Ukraina, Vatikan, Yaponiya, Afg‘oniston, Bangladesh, Bruney, Birma, Kambodja, Laos, Maldiv orollari, Mo‘g‘uliston, Nepal, Shimoliy Koreya, Janubiy Koreya, Iroq, Isroil, Eron, Saudiya Arabistoni, Suriya, Avstraliya, Yangi Zelandiya, Fiji, Kanada, Amerika, AQSh, Beliz, Bermuda, Dominika, Nikaragua, Panama, Argentina, Braziliya, Chili, Kolumbiya, Urugvay, Peru, Venesuela, Afrika, Uganda, Zambiya, Zimbabve, Tanzaniya, Somali, Sudan, Niger, Nigeriya, Mali, Marokash, Madagaskar, Liviya, Misr, Efiopiya, Iordaniya, Ekvador, Tailand, Buyuk Britaniya, Meksika, Braziliya, Argentina, Filippin, Vetnam, Turkmaniston, O‘zbekiston, Qozog‘iston, Yaman va boshqalar.

Issiq teglar: fraksiyonel hp motor, Xitoy, etkazib beruvchilar, ishlab chiqaruvchilar, zavod, ulgurji, narx
